New DJI M3 Tethering Module Tethered Power Supply
Main features
1. Small size, light weight, backpack design, easy to carry;
2. Easy to operate, no need to operate during UAV flight;
3. No need to change the structure of the UAV, can quickly switch flight modes;
4. Automatic reel in/out, and manually rewind when there is no power;
5. Airborne power supply constant voltage output;
6. Support flight duration: ≥ 24h;
7. Support flight altitude: 50-100m (tethered cable 110m);
8. Optional lighting: 640W(JM640)
Air module power supply
1. Replace one original battery, plug and install it the same way;
2. Output constant voltage: 25.5±0.3Vdc;
3. Output power: rated 2000W, peak 2500W;
4. Size: 156*75*45±0.5mm;
5. Heat dissipation method: Equipped with fan for heat dissipation;
6. Weight: 570±20g;
7. Protection level: IP54;
Ground module
1. Input voltage: single-phase 220Vac@50/60Hz; Output voltage 400V dc;
2. Cable length: 110m, Optional 160m;
3. Cable reel in and out automatic or manual reel in/out when power OFF(Battery Built inside);
4. Alarm: Audible and visual alarm;
5. Size: W180*D360*H260±0.5mm;
6. Weight: 8.5±0.2kg (110m cable, 10g/m);
7. Protection level: IPx5;
8. Working temperature: -20~45 ºC;
9. Altitude: 3000m;
10. Winding speed and tension: 0-2m/s, 0-10N, adjustable
11. Communication: Wired communication with serial protocol, wireless communication with Bluetooth or wireless serial protocol
12. Warning: When a fault occurs, the display screen scrolls and the warning light sounds and lights to remind you
13. Display: 4.0 "touch screen displays data such as voltage, current, temperature, outlet length, date, fault records, and working status
14. Settings: Settings for speed, tension, safe distance, and date, switching between Chinese and English
Lighting unit
640W lighting unit
Typical characteristicsSmall size, light weight, suitable for small and medium-sized multi-rotor UAV;
Large area, high illumination, suitable for various lighting operation scenarios;
It has the functions of short circuit protection, overtemperature protection and tied power failure protection;
With stepless dimming and flash function, simple operation and strong adaptability;Performance characteristicsInput voltage: 10~60V wide voltage range input;
Lighting power: rated power 640W, short-term peak power up to 720W;
Luminous flux: 80000lm (total amount of light emitted by light source, independent of height and lens angle) Illuminance (brightness): that is, the light intensity, the total amount of light received per unit area, and the illuminance in the effective illumination area tends to average
1) 180lux/20m height
2) 100lux/30m high
3) 60lux/50m high
4) 13lux/100m high
Effective lighting area: effective lighting operation area (about 65% of the maximum lighting area), which can be customized according to requirements, with a maximum height of 10000 m2/30m
1) 760 m2/20m high
2) 1700 m2/30m high
3) 4800 m2/50m high
4) 10000 m2/75m high
